Memory device is serial eeprom 24c04, download connection diagram.
Expected file size is 512 bytes
Use Texas Crypto transponder or original Ducati handsfree key.
If you program original handsfree key, to activate handsfree function you must remove battery from key for 5 seconds.
If you program transponder, to start bike you must put it near antenna. Look here where is antenna located.
Written transponder or key is ready programmed to start bike.
Vehicles equipped with this unit:
Ducati:Diavel, Multistrada
