Memory device is Motorola 9S12XS256.
You can read Motorola 9S12XS256 with TMPro, view connection diagram.
Expected file size is 8192 bytes.
If Motorola is LOCKED, software will unlock it automatically before to read eeprom area.
Also you can synchronise engine ECU and immobox if they are not matched pair.
Software can program:
– UNLOCKED BMW handsfree key.
– Texas Crypto 128-bit AES transponder.
Written handsfree key or transponder are ready programmed to start bike.
IMPORTANT NOTE 1: in case you use transponder you must place it close to antenna for to start bike. In case you use handsfree key you must place it close to antenna for EWS to adopt it. View different antenna locations.
IMPORTANT NOTE 2: BMW motorbike EWS use 3 different frequencies – 434.42 MHZ , 433.92 MHz and 315 MHz. If you use VVDI BMW motorcycle remote key you must prepare it to right frequency before to program it with software.If remote key is with fixed frequency,it must be 100% same as shown on TMPro screen.
Vehicles equipped with this unit:
BMW: R1200GS,R1250GS,C400,F900
